Butt Hinge: Steel, Full Mortise, 1 7/8 in Leaf Wd
In Stock
$27.00
Save 13%
$23.56
/each
Earn 23 points for this item
($0.23 for your next purchase!)
REGISTER NOW TO EARN!
ETA 5-7 BUSINESS DAYS
Request quantity discount pricing
You're Viewing
MCKINNEY Butt Hinge: Steel, Full Mortise, 1 7/8 in Lea...
Mfr # 4 1/2X4 1/2 MPS60 26D
$23.56
Customers Also Viewed
No related products found.
Product Details
| Brand | MCKINNEY |
| Storage Protection Code | A |
| Product Powered by Fossil Fuel | N |
| Door Leaf Width | 4-1/2 in |
| Includes California Prop 65 Short-Form Warning | Y |
| Load Capacity | 250 lb |
| UL Fire Rating | UL10C |
| Door Thickness - Maximum | 1-3/4 in |
| Ozone Depleting Substance | N |
| Is this a Hazardous Material Product? | N |
| Prop65_WarningMessage | Compliance_Prop65_Short_CancerandRepro |
| Door Leaf Height | 4-1/2 in |
| Bearing Type | Plain |
| RoHS - Restricted Use of Hazardous Substances Directive (RoHS) | N |
| Frame Leaf Thickness | 0.134 in |
| Material | Steel |
| Contains California Prop 65 Reproductive Toxicant | Y |
| Contains California Prop 65 Carcinogen | Y |
| Display Qty | 1 |
| Pin Diameter | 11/16 in |
| Manufacturer Part Number | 4-1/2X4-1/2 MPS60 26D |
| Freight Class Code | 18 |
| Number of Holes per Leaf | 4 |
| Corner Type | Square |
| Includes Hardware | Hardware Included |
| Range of Motion - Maximum | 180 Degrees |
| Mounting Style | Full Mortise |
| EnvironmentallyPreferable_Indicator | N |
| Door Leaf Thickness | 0.134 in |
| Finish | Chrome, Satin Chromium-Plated |
| Pin Material | Steel |
| Fire Rating | 3 hr |
| Frame Leaf Height | 4-1/2 in |
| Standards | NFPA 80, ANSI/BHMA A156.17, ANSI/BHMA A156.1, UL Listed, ANSI/BHMA A156.7 |
| Should Sales be Restricted by Region? | N |
| Overall Width | 4-1/2 in |
| Sub-brand | Spring Hinge |
| Safety Data Sheet (SDS) Applicable? | N |
| Display Sell UOM | EA |
| Door Thickness - Minimum | 1-3/4 in |
| Frame Leaf Width | 1-7/8 in |
| Hand Orientation | Non-Handed |
| Number of Holes | 8 |
| Features | NFPA Requires a Minimum of Two Hinges on Labeled Doors, For Standard Weight Hinge Applications Requiring Self-Closing Control |
| Mfr. Model # | 4 1/2X4 1/2 MPS60 26D |
Description
Full Mortise Hinge, 180 deg., 4-1/2" W
